Next.js App Router Migration

As Next.js App Router structure becomes stable and claimed production-ready, I have been wondering how potential changes it will bring to company projects. Hence starting the journey by migrating this blog to the new structure.

cat is smiling

Why App Router?

As an e-commerce site built on Next.js with support of internationalization and localization (i18n), we are utilizing i18next, particularly next-i18next with getStaticProps (SSG). As the site grows, we have more contents and namespaces for translation, which brings an increase of the initial payload loaded by html script __NEXT_DATA__. This is not ideal for SEO and performance in the long run, especially some pages have already shown a Large Page Data warning which exceeds default largePageDataBytes of 128kB.

This load of static props occurs on every page, even if previous pages have loaded common namespaces. With next/link it will trigger a preload request on any Next.js page and cause unnecessary data fetching.

This is where layout components come in handy in Next.js app router structure. React Server Components (RSC) support loading data once and pass props down to children components. This translation context could be shared across client-side components without the need to fetch data again.

Migration of this blog

With the bright (promised) future of App Router, I started moving exploring available options and gradually replacing the following

  1. Migrate /pages/_app.tsx and /pages/_document.tsx
  2. Move /pages/* page to /app/*/page.tsx
  3. Replace getStaticProps or getServerSideProps with direct server call
  4. Configure and restructure Markdown pages /*.mdx
  5. Move /pages/api/* page to /app/api/*/route.ts (TODO)

Thankfully, Next.js team has provided a well written instructions and examples on how to migrate from App Pages to App Router. However, there are still some caveats and gotchas that I would like to record and share. Let's start it step by step.

First of all, please check all requirements of node.js, Next.js and related plugins. Then start it with updating next.config.js to enable App Router (which could be experimental depending on the version of Next.js).

// next.config.js
const config = {
  ...
  experimental: {
    ...
    appDir: true,
  },
}

1. Migrate /pages/_app.tsx and /pages/_document.tsx

As Next.js introduces new layout similar to astro island design, we can create a RootLayout under app folder

Before

// pages/_document.tsx
<Html lang="en">
  <Head>
    {/* head scripts */}
    <script />

    {/* assets */}
    <link rel="apple-touch-icon" sizes="180x180" href="/apple-touch-icon.png" />
    <link rel="icon" type="image/png" sizes="32x32" href="/favicon-32x32.png" />
    <link rel="icon" type="image/png" sizes="16x16" href="/favicon-16x16.png" />
    <link rel="manifest" href="/site.webmanifest" />
    <link rel="alternate" type="application/rss+xml" href={`${config.domain}/rss/feed.xml`} />
    <link rel="alternate" type="application/feed+json" href={`${config.domain}/rss/feed.json`} />

    {/* meta */}
    <meta name="msapplication-TileColor" content="#ffffff" />
    <meta name="theme-color" content="#ffffff" />
  </Head>
  <body>
    <Main />
    <NextScript />
  </body>
</Html>

// pages/_app.tsx
<>
  {/* SEO settings from next-seo https://www.npmjs.com/package/next-seo */}
  <DefaultSeo {...DEFAULT_SEO} />

  {/* some layout with css */}
  <Header />
  <main>
    <Component previousPathname={previousPathname} {...pageProps} />
  </main>
  <Footer />
</>

After

// app/layout.tsx
import "@/styles/globals.css"

import type { Metadata } from "next"

export const metadata: Metadata = {
  // ... replacing Head under _documents.tsx
}

export default function RootLayout({ children }) {
  return (
    <html lang="en">
      <body>
        {/* some layout with css */}
        <Header />
        <main>{children}</main>
        <Footer />
      </body>
    </html>
  )
}

2. Move /pages/* page to /app/*/page.tsx

As Next.js implements RSC on all components under /app, if we want to use any client side logic or APIs, we will need to specify 'use client' on top of each file to skip usage of RSC, or we can split the client-side parts into a new file with 'use client' and import it in the RSC file.

For example,

Before

// pages/some-page.tsx
import { useState } from "react"

export default function SomePage() {
  // client side react hooks
  const [someState, setSomeState] = useState()

  return (
    <div>
      <h1>Some Page</h1>
      {/* client side  */}
      <button
        onClick={() => {
          setSomeState()
        }}
      >
        Click
      </button>
    </div>
  )
}

After

// app/some-page/page.tsx
import ClientComponent from "./ClientComponent"

export default function SomePage() {
  return (
    <div>
      <h1>Some Page</h1>
      {/* client side  */}
      <ClientComponent />
    </div>
  )
}

// app/some-page/ClientComponent.tsx
"use client"

export default function ClientComponent() {
  // client side react hooks
  const [someState, setSomeState] = useState()

  return (
    <button
      onClick={() => {
        setSomeState()
      }}
    >
      Click
    </button>
  )
}

3. Replace getStaticProps or getServerSideProps with direct server call

With the help of RSC we can directly modify server components with server-side logic using async & built-in React.Suspense, instead of receiving props from components. To correctly set up similar behaviours of getStaticProps or getServerSideProps, please verify your needs and reference Route Segment Config for customisation.

Before

// pages/some-page.tsx
import ClientComponent from "./ClientComponent"

export default function SomePage({ someProps }) {
  return (
    <div>
      <h1>Some Page</h1>
      {/* client side  */}
      <ClientComponent someProps={someProps} />
    </div>
  )
}

export async function getStaticProps() {
  const someProps = await fetchSomeProps()

  return {
    props: {
      someProps,
    },
  }
}

After

// app/some-page/page.tsx
import ClientComponent from "./ClientComponent"

export default async function SomePage() {
  const someProps = await fetchSomeProps()

  return (
    <div>
      <h1>Some Page</h1>
      {/* client side  */}
      <ClientComponent someProps={someProps} />
    </div>
  )
}

For instance, notice that we cannot directly import RSC under client-side components, instead we can pass the whole React.node as props to client-side components.

Advanced

// app/some-page/page.tsx
import ClientComponent from "./ClientComponent"
import ServerComponent from "./ServerComponent"

export default async function SomePage() {
  const someProps = await fetchSomeProps()

  return (
    <div>
      <h1>Some Page</h1>
      {/* Here assuming ClientComponent accepting children as props  */}
      <ClientComponent someProps={someProps}>
        <ServerComponent />
      </ClientComponent>
    </div>
  )
}

// app/some-page/ServerComponent.tsx
export default async function ServerComponent() {
  // could be any other server-side call
  const someProps = await fetchSomeProps()

  return (
    <pre>
      <code>
        {/* rendered based on someProps */}
        {JSON.stringify(someProps, null, 2)}
      </code>
    </pre>
  )
}

4. Configure and restructure Markdown pages /*.mdx

This is probably the part that I got stuck on for the longest. Currently I'm importing images directly to *.mdx files together with next/image for image optimisation. This native support from Next.js on Vercel displays a consistent user perception on different devices with lazy loading, but here comes the problem.

As recommended by Next.js doc, we are enabling mdxRs: true in config and add mdx-components.tsx to root folder.

// next.config.js
/** @type {import('next').NextConfig} */
const nextConfig = {
  experimental: {
    mdxRs: true,
  },
}

const withMDX = require("@next/mdx")()
module.exports = withMDX(nextConfig)

import type { MDXComponents } from "mdx/types"

export function useMDXComponents(components: MDXComponents): MDXComponents {
  return components
}

However, this breaks the image import in *.mdx files. The error message is not very helpful, but it seems like the mdxRs is not compatible with next/image yet. Hence I have to disable mdxRs so it compiles successfully.

Unhandled Runtime Error

Error: Could not find the module "/Users/howard86/Projects/howardism/node_modules/.pnpm/next@13.4.10_@babel+core@7.22.9_react-dom@18.2.0_react@18.2.0/node_modules/next/dist/client/image-component.js#Image" in the React Client Manifest. This is probably a bug in the React Server Components bundler.

By the time of writing, this unexpected behaviour appears at version 13.4.10 of Next.js. By disabling mdxRs, it seems to fix the issues for now. It could be caused by my custom export of meta in mdx files, which does similar results as to gray-matter but exporting a custom StaticImage from custom Next.js image import.

5. Move /pages/api/* page to /app/api/*/route.ts (TODO)

This is the part that I haven't started yet. The main bottlenecks or concerns are I'm using next-api-handler to handle API routes, and I'm also the maintainers of the package. By the time of writing, after evaluation of the current implementation of next-api-handler, there will be some breaking changes to introduce support of App Router (which is similar to Edge Handlers in Vercel). I will update this part once I have started the migration.

Conclusion

As Next.js App Router is getting more and more popular with significant improvement on server-side data-fetching, it is definitely worth to migrate to the new structure. However, there are still some caveats and gotchas that we need to be aware of. I hope this article could help you to get started with the migration and share your experience with me.
